:: FunFly Controller "NAZE32"
FunFly Controller "NAZE32"
Starting at: 5,000JPY
There might be a distributor carrying these boards near you! Check regional availability first:
United States 1
United States 2
United States 3
LIMITED STOCK AVAILABLE, SAVE MY TIME AND ORDER FROM NEARBY DISTRIBUTOR INSTEAD!
Mini Flight Controller 「なぜ32」 (pronounced "NAZE32").
5.3 grams (no headers, 7.3 grams with)
2000 degrees/second 3-axis MEMS gyro + accelerometer (MPU6500)
3-axis magnetometer (HMC5883L)
Pressure sensor (MS5611)
Flexible motor outputs, support various airframe types -
Quad/Hexa/Tri/Bi/Y4/Y6/Octo/Camera Gimbal. (Default is Quad-X)
Up to 8 ch RC input - supports standard receivers (PWM), PPM Sum receiver (FrSky, etc), Spektrum Satellite, as well as Futaba/FrSky SBUS receiver.
Built in FrSky telemetry inverter (shared w/main port)
Built in SBUS inverter
Battery voltage monitoring
Modern 32-bit processor running at 3.3V/72MHz (STM32F103CB).
128Mbit onboard SPI flash
Onboard MicroUSB for setup and configuration
LEDs so bright, they will blind you
MultiWii-based configuration software for easy setup
Made in JAPAN
Designed for use with small indoor or small to mid-sized outdoor multirotor craft, or as a standalone camera stabilizer, the Naze32 flight control is simple to setup, with configuration based on the familiar “MultiWii” software.
2x5 pin header
10x1 pin header
3x6 right angle header
1x RC breakout cable (order-time option, not selected by default).
User's Manual for rev5
User's Manual for rev4
Configuration software - Chrome Baseflight Configurator
Software is open-source! Code repository at
Note: Currently shipping rev6 boards in random colors.
Hardware specifications and layout are subject to change without notice for improvement. Letter revisions (i.e. REV6A,B,C, etc) are for correcting non-critical issues or manufacturing optimizations.
Note: This hardware cannot be used with any DJI frames. This includes: FlameWheel 330, 450, 550, or any future or past frames released by DJI.
Note: Using this hardware with anything other than supplied "baseflight" firmware will immediately make the end user ineligible for any kind of support or warranty.
Shipping Weight: 0.04kilograms
0 Units in Stock
Manufactured by: AbuseMarK
Include RC Breakout Cable
No, I have a PPM receiver or don't need the cable.
Yes, I don't have PPM receiver or I need the cable ( +100JPY )
Pin Header Type
Standard Vertical headers for all pins
Right-angle 3x6 header for motors, 2 vertical for other pins. ( +100JPY )
No support - I know what I'm doing
What's a command line? ( +5,000JPY )
I'm not sure where "#" key is ( +10,000JPY )
Qty Discounts New Price
* Discounts may vary based on options above
This product was added to our catalog on Thursday 16 February, 2012.
